Sufficient air is needed for proper combustion and exhausting of gases through the flue, (chimney) of fuel burning equipment to prevent backdraft. 3. 4. *This manual in electronic format may be downloaded from our company website or obtained from the dealer. Please retain this booklet for future reference.
This unit is appropriate for wall installation in a non-wet application. Finsh ceiling work.
utilitech inspectapedia Insert mounting springs into slots and mount grille to fan body. 7. When cutting or drilling into wall or ceiling, do not damage electrical wiring and other hidden utilities. 3.
Follow the heating equipment manufacturer's guideline and safety. 10. To reduce risk of fire and to properly exhaust air, be sure to duct air outside. Follow all local electrical and safety codes, as well as the National Electrical Code (NEC), and the Occupation Safety and Health Act (OSHA).
SUPPLIED ACCESSORIES Grille or G15 or G16 or L5 L6 Suspension bracket assembly 1 Long screw (ST4X30) 5 Wire Protector Nut 1 Installation instructions 1 DESCRIPTION These bath fan models are listed by ETL under ETL file No.5011292. specification label on product for further information and requirements. HVI Certified performance based on HVI Procedures 915, Other airflow reference performance based on HVI, Manual will be automatically added to "My Manuals", Fan aero pure VSF110D-S Installation Manual, Fan aero pure VSF110DH-S Installation Manual, Fan aero pure ABF110DHG5 Series Installation Instructions Manual, Fan aero pure AP80RVL Installation Manual, Fan aero pure ABF110DHG1 Series Installation Instructions Manual, Fan aero pure AP80-QVL Installation Manual.
Refrigeration and Air Conditioning Engineers (ASHRAE), and the local code authorities.
A 4, 5, or 6circular duct is needed to connect to relevant part of adaptor.
bathroom exhaust fans fan mobile aero pure ventline cfm slimfit energy star mounted side slim ap90 Use this unit only in the manner intended by the manufacturer. INSTALLATION II (RETROFIT) CONTINUED 4. Please read the instructions carefully before attempting, to install, operate, or service our bath fan. IMPORTANT: Remove the tape from damper and adaptor before installation. These bath fan models use a Sirocco fan driven by a capacitor motor.
Not for use in kitchens.
ventilation 2578 WARNING -TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, PLEASE READ. 3.
GENERAL SAFETY INFORMATION 1. When the service, disconnect cannot be locked, securely fasten a prominent warning device, such as a tag, to the service panel. (Fig.5) CAUTION: Hold the fan body to prevent falling before fixing the screws. Duct Air Voltage Frequency Noise diameter direction (V) (Hz) (sones) (inches) Power consumption (W) Fan Light N.Light Air volume Speed at 0.1"WG (rpm) (CFM) ABF80G15OR ABF80G15SN Exhaust 120 60 4, 5, 6 0.4 18.7 849 80 Exhaust 120 60 4, 5, 6 0.4 18.7 849 80 ABF110G15SN Exhaust 120 60 4, 5, 6 1.1 25.2 1140 110 120 60 4, 5, 6 1.1 25.2 1140 110 Exhaust 120 60 4, 5, 6 0.3 18.4 10 0. BATH FAN INSTALLATION INSTRUCTIONS Model No. Fig.19 PRACTICAL GUIDE TO INSTALLATION Properly insulate the area around the fan to minimize building heat loss and gain.
(3) The toggle switch will adjust the upper fan speed setting from 80 to 120 CFM. Push the fan body upwards until the fan body is secure with the joint, and secure them by using the remaining 3 self-drilling screws(ST4X30) (Fig.15) 5.
sone rona ABF80G15 Series ABF110G15 Series ABF80G16 Series ABF110G16 Series ABF80L5 Series ABF110L5 Series ABF80L6 Series ABF110L6 Series READ AND SAVE THESE INSTRUCTIONS Thank you very much for purchasing our bath fan.
For quiet and efficient operation, long life, and attractive appearance - lower or remove grille and vacuum interior of unit with the dusting.
installation only).
lightology Installer: Leave this manual with the homeowner.
manualzz WARNING: To reduce the risk of fire or electric shock, do not use this fan with any solid-state speed control device. (Fig. (b) When humidity rises above a user-adjustable set point (50-100% Relative. 2) The humidity sensor for setting the proper relative humidity level in the room. .. . . . .. . . . Low Profile 110 CFM Quiet Ceiling Bathroom Ventilation Fan 0.9 Sones, White. Do not vent exhaust air into spaces within walls or. INSTALLATION INEW CONSTRUCTIONCONTINUED Buckle 5.Push the fan body upwards until the fan body is stopped by the buckle on the adapter and secure the fan body by using the remaining 3 self-drilling screws (ST4X30).
aero pure fan ventilation g6 qualified quiet cfm energy bathroom star sbf super ap very
Installation work, and electrical wiring must be done by a licensed person(s) in accordance with all applicable codes and standards, including fire-rated, construction codes and standards. SPECIFICATIONS Model No. Put the folded bracket assembly into ceiling hole, then follow step 3-4 of Installation I (NEW CONSTRUCTION page 5) to complete the extra spacebracket installation.
Please read the instructions carefully before attempting to install, operate, or service our bath fan.
(Fig.18) Fig.18 5. Thank you very much for purchasing our bath fan. Install a circular duct and secure with clamps or ties and seal with mastic or approved foil tape. Caulk Celling Fig.8 9.
CAUTION: 1. Both 4" and 6" duct adaptors are included.
1. DIMENSIONS Series: ABF80L6, ABF110L6 Unit: inches (mm) 5 4/5 (147) 4 7/8 (123) 3 7/8 (98) 10 2/5 (265) 3 4/5 (97) 10 1/4 (260) 12 1/8 (308) 7 1/3 (186) Blade Grille Adaptor Damper Fan body 6 7 8 9 10 Knock-out plate Junction box Capacitance box Bracket assembly LED light 3/5 (14. Remove dust and dirt from fan body using a vacuum cleaner.
ventilation selector smartflow whisperceiling (a) When someone enters then leaves the room.
Align ceiling hole with the inside edges of the flange. off power unit. 11.
The fan must not be. The motor is permanently lubricated and never needs oiling.
aero pure ventilation sbf fan g5 qualified quiet cfm energy bathroom super star trim stainless steel silver 5. Install fan at least 2.5 m (8.2 feet) above the floor. 4. servicing or cleaning unit, switch power off at service panel to prevent power from being switched on accidentally. Failure to comply with instructions could result in personal injury or property damage.
pure aero visit
Failure to comply, with instructions could result in personal injury or property.
sones Using a cloth dampened with kitchen detergent, remove any dirt from fan body then wipe dry with clean cloth. (Fig.12) Unit: inches (mm) A 10 3/5 (27 0) (270) 10 3/5 B screws (ST4x20) Fig.12 2. damage. Please retain this booklet for future reference. This product is designed for, installation in ceilings up to a 12/12 pitch (45 degree angle). 5.
(Fig.8) 2/5 Unit: inches (mm) (26 5) 10 2/5 (26 5) 10 IMPORTANT: After finishing the celling work, fill gap between flange and celling with caulk or other sealant to prevent air leakage. Unit is, acceptable for use over a tub or shower when connected to a GFCI (Ground Fault Circuit Interrupter) protected branch circuit (ceiling. (Fig.19) 6. (Fig. 9.
ap90 light aero pure bathroom fans bath ventilation sones quiet cfm ceiling led fan low night profile
using a 4" duct or 90 to 140 CFM using a 6" duct. This unit must be grounded.
extractor nickel fan cyclonic aero satin pure technology convection heater email rona exhaust sones hvi 2. Follow step 10 of Installation I (NEW CONSTRUCTION page 7-8) to complete installation.
Duct connector must point upward for wall application. Do not install this bath fan where interior room temperature may exceed 104F (40C). As shown below: 4 screws (ST4x30) Joist situation: Fig.1 L Two cases of spacing L : A 12 inches (305 mm) B 16~24 inches (406~610 mm) A B If the spacing L is 12 inches (305 mm) on joists, please follow the installation step as (Fig.1).
a515 aero
installed in a ceiling thermally insulated to a value greater than R40.
4. For general ventilating use only.
exhaust ceilings or into attics, crawl spaces, or garages. 8.
2. INSTALLATION INEW CONSTRUCTIONCONTINUED 8. Fan body 3 Screws (ST4x30) Fig.5 6.Install a circular duct and secure it with clamps or ties and seal it with mastic or approved duct tape. MAINTENANCE (CLEANING) CONTINUED 4.
aero sone 13.
aero pure slim exhaust fan g6 cfm ceiling mount series ferguson bathroom Do not use to exhaust hazardous or explosive materials and vapors. Please read.
UNPACKING Unpack and carefully remove the unit from carton. Always disconnect the power source before working on or near the fan, motor, light fixture, or junction box. THE FOLLOWING PRIOR TO INSTALLING THE FAN: 1. Secure 4 screws (ST4X30) at flange of frame to the joists.
aero pure fans fan builders INSTALLATION IIRETROFIT 1. Ducted fans must always be vented to the outdoors. Refer to the supplied accessories list to verify that all parts are present.
standards such as those published by the National Fire Protection Association (NFPA), and the American Society for Heating. Routine maintenance must be done every year.
Reinstall Grille. If you have questions, contact the manufacturer.
The control box, located inside the fan housing, has three separate, (1) The time delay knob which is adjustable from 5 to 60 minutes and switches the. 3 Screws (ST4x30) Fig.15 MAINTENANCE (CLEANING) WARNING: Disconnect power source before working on unit.
